Ultra 125U Industrial Computer

Model: Partaker I38-A

Powered by Intel Core Ultra 5 125U (up to 4.3GHz) with Intel AI Boost NPU.
Supports quad independent displays via 4x HDMI and 2x Type-C (up to 4K@60Hz).
Rich I/O: 6 COM ports (4x RS485, 2x RS232) and isolated 4-in/4-out GPIO.
Equipped with 2x Intel I226-V 2.5G LAN, optional 3rd LAN and vPro support.
Supports up to 32GB DDR5 5600MHz SODIMM memory.
Dual M.2 2280 NVMe PCIe 4.0 slots for high-speed storage (optional 2.5″ bay).
Flexible expansion: 3x M.2, 2x Mini PCIe, and 2x onboard SIM slots.
Wide voltage DC 12-24V input via 2-pin Phoenix connector.
Premium aluminum alloy chassis with wide temp support (-20°C to +50°C).
Ideal for Edge AI, industrial automation, medical, and machine vision.

Share to:

Overview

The Ultra 125U Industrial Computer is a high-performance, rugged industrial computing platform powered by an Intel Core Ultra 5 125U processor (12 cores/14 threads, up to 4.3GHz). It features comprehensive industrial connectivity, including 6 COM ports (4x RS485 + 2x RS232), isolated 4-in/4-out GPIO with 9–24V input, 2x 2.5G LAN, and 4x USB. For multi-display applications, it supports 4-display output via 4x HDMI and 2x Type-C. Flexible expansion is provided by 3x M.2, 2x Mini PCIe, and 2x Nano-SIM slots, while DC 12–24V Phoenix terminal input ensures stable operation in demanding environments. Ideal for automation, medical, logistics, and machine vision applications, the Ultra 125U Industrial Computer delivers reliable performance, rich I/O, and flexible deployment for industrial edge and embedded systems.

Mechanical

System Parameter
Model	Partaker I38-A
Chassis	Premium aluminum alloy + sheet metal structure
BIOS	AMI EFI BIOS
Processor	Intel® Core™ Ultra 5 125U (12C/14T, up to 4.3 GHz)
Processor	Optional Ultra7 155U, Ultra7 155H, Ultra5 225U;
Memory	Support 1*DDR5 5600MHz SODIMM memory slot, up to 32GB.
NPU	Intel® AI Boost（Max Frequency 1.4 GHz）
Display Chip	Intel Graphics
Display port	4× HDMI,2× Type-C (sync/async quad display, up to 4096×2160 @ 60Hz)
Storage	2× M.2 2280 M-key; optional 1× 2.5″ drive bay
Expansion Slots	2× M.2 2280 M-key (NVMe, PCIe 4.0 x4) 2× Mini PCIe (supports 4G/WiFi,PCIe + USB 2.0 ), 2× onboard SIM slots
Expansion Slots	1× M.2 2230 E-key (supports WiFi/BT,PCIe + USB +CNVio2 ) Optional (not populated by default): 8× GPIO
Other Function	Power-on, Time-on, Wake-on-LAN, UEFI PXE boot, watchdog (0–255 levels), TPM 2.0
Front I/O	4× HD-MI, 2× Full-function Type-C (DP / USB 3.2 / PD 5V 1A) 1× 2P DC input, power button, 1× audio combo jack, CLRTC button
Front I/O	1× 4-in/4-out GPIO (optically isolated, 9–36V support), 6× COM (COM1–4: RS485, COM5–6: RS232)
Network	2× Intel I226-V 10/100/1000/2500M Ethernet (optional 3× LAN) LAN1 optional Intel I226-LM 2.5 Lan,Support Intel vPro (not populated by default)
Power Supply	DC 12–24V wide voltage input, 2-pin 5.08mm Phoenix connector
Certificates	CE、 FCC Class A、 ROHS
Application	Edge AI Computing, Industrial Automation，Medical，Logistics Transportation, Warehousing, Machine Vision, etc.
Structure Parameter
Color	Black &Blue (Color can be customized)
Material	Aluminum alloy chassis
Size	190×136×48 mm (excluding wall-mount bracket)
Weight	1.49KG(including wall-mount bracket)
Environmental Parameter
Work Temp	0℃ ～ +40℃（Commercial HDD），-20℃ ～ +50℃（Industrial SSD），Surface air flow
Work Humidity	5% ～ 95% non-condensing

Accessories List
Name	Quantity	Specification
Power Adapter	1	12V 7.5A
Power Cord	1	US,UK,EU,etc, optional
Qualification	1	Neutral
Warranty card	1	Neutral
VESA mount	2	Standard

Order Information
Configuration 1	I38-A	Intel Ultra5 125U,2LAN/4USB/Type-C/6COM / GPIO	Standard Port
Configuration 2	I38-A	Intel Ultra5 125U,3LAN/2USB/Type-C/6COM / GPIO	Standard Port
