Industrial Mini PC with Dual LAN
Model: Partaker I34
- Gray casing (customizable) for industrial environments
- Intel Celeron J1900 or 4th-8th Gen Core i3/i5/i7 (model varies)
- Up to 32GB DDR3/DDR4 RAM for multitasking
- 1 x mSATA + 1 x SATA 2.5″ for versatile data options
- 2 x Mini PCIe (1 x 4G/WiFi, 1 x WiFi), 6x COM ports
- HDMI, 4 x USB 3.0, 2 x USB 2.0, dual Gigabit Ethernet
- -20°C to 60°C (SSD), 0°C to 50°C (HDD)
- Auto power-on, watchdog timer, Wake-on-LAN, PXE boot
- CE/FCC Class A/RoHS approved
- Ideal for automation, medical, logistics, and machine vision
Share to:
Overview
This industrial computer combines a durable aluminum alloy build with customizable gray finishes, supporting processors from Intel Celeron J1900 to 4th-8th Gen Core i3/i5/i7. It features up to 32GB RAM, Intel UHD Graphics, and versatile connectivity including dual Gigabit Ethernet, Mini PCIe for 4G/WiFi, and 6x COM ports. Operating from -20°C to 60°C (SSD), it’s certified CE/FCC/RoHS and ideal for automation, medical, and logistics.
Mechanical
| Specification | |
| Model | Partaker I34 |
| Color | Gray (color can be customized) |
| Material | High quality aluminum alloy |
| Processor | Intel Celeron J1900 |
| 4th /5th gen Intel Core i5/i7 (specific model subject to shipment) | |
| 6th /7th /8th gen Intel Core i3/i5/i7 (specific model is subject to shipment) | |
| Memory | DDR3/DDR4 laptop memory slots Max.32GB,the order information at the end of this page for details |
| BIOS | AMI EFI BIOS |
| Display chip | Intel UHD Graphics |
| Display Port | 1*HDMI |
| Storage | 1*MSATA,1*SATA 2.5 inch hard disk |
| Expansion slot | 2*Mini PCIE (1*support WIFI/Bluetooth/3G/4G with SIM card holder, the other support wifi) |
| I/O port | 1*DC power supply , 1*HDMI , 4*USB3.0, 2*USB2.0 (J1900: 1*USB3.0 , 5*USB2.0) |
| 6*COM (COM1-2 RS232/485),1*Audio two-in-one , 1*power button | |
| 2* Realtek Gigabit network ports, support Wake on LAN /PXE, 1* CLEAR CMOS button | |
| Expansion Port | Standard shipments have not this port, customization: GPIO (4-in-4-out) |
| Network | 2* RTL8111H 10M/100M/1000M Gigabit network ports |
| Input Voltage | DC 12V input, customizable DC 9~36V wide voltage input |
| Other functions | Auto power on、Timing boot、Wake on LAN、PXE boot、watchdog (level 0~255) |
| Work Temperature | 0℃ ~ +50℃ (hard disk), -20℃ ~ +60℃ (solid state drive), surface air flow |
| Work humidity | 5% ~ 95% non-condensable state |
| Certificate | CE、 CCC、 FCC Class A、 RoHS
|
| Dimension | 260 * 173 * 61 mm |
| Weight | 2.5 kg |
| Installation | Wall-mounted, Desktop |
| Certificate | CE、 FCC Class A、 RoHS |
| Application | Industrial automation, medical, Logistics & Transportation, Warehouse , Machine Vision ,etc. |
| Packing List | ||
| Name | Quantity | Specifications |
| Power Adapter | 1 | Optional 12V 5A/7.5A |
| Power Cable | 1 | Optional CN, US, EU plug,etc. |
| Wall screws | 4 | Standard |
| Order Information | ||||
| Configure | Processor | Standard I/O Port | Internal expansion | remarks |
| Configuration 1 | Intel Celeron J1900 | LAN*2/USB*6/COM*6/ HDMI*1/ DC-IN*1/Audio*1 | 1*DDR3/8G Max/1*m SATA/1*2.5” HDD/2*mini_PCIE wifi/(3G/4G) | Please consult our sales staff for details |
| Configuration 2 | 3th Gen Intel Core i3/i5 | LAN*2/USB*6/COM*6/ HDMI*1/DC-IN*1/Audio*1 | 1*DDR3/8G Max/1*m SATA/1*2.5” HDD/2*mini_PCIE wifi/(3G/4G) | |
| Configuration 3 | 4/5th Gen Intel Core i5/i7 | LAN*2/USB*6/COM*6/ HDMI*1/ DC-IN*1/Audio*1 | 2*DDR3/16G Max/1*m SATA/1*2.5” HDD/2*mini_PCIE wifi/(3G/4G) | |
| Configuration 4 | 6/7th Gen Intel Core i3/i5/i7 | LAN*2/USB*6/COM*6/ HDMI*1/ DC-IN*1/Audio*1 | 2*DDR4/32G Max/1*m SATA/1*2.5” HDD/2*mini_PCIE wifi/(3G/4G) | |
