1U Firewall Pfsense Mikrotik 6 Lan 2 Intel SFP

1U Firewall Pfsense Mikrotik 6 Lan 2 Intel SFP

Model: Partaker S11

  • Sheet Metal Structure and Fan Design: The product features a sturdy and durable sheet metal structure along with an optimized fan design, ensuring efficient cooling and maintaining optimal operating temperatures for the components.
  • Support for Intel Core i3-3110M Quad-Core Processor: The product is compatible with the Intel Core i3-3110M quad-core processor, offering reliable performance for various computing tasks.
  • DDR3L 1600 Support with up to 8GB: The product supports DDR3L 1600 memory technology, allowing for a maximum capacity of 8GB. This enables smooth multitasking and efficient data processing.
  • Storage Options: The product offers versatile storage options, including one mSATA slot for high-speed solid-state storage and one 2.5-inch hard disk drive slot for additional storage capacity, catering to different storage needs.
  • 1U Chassis with 6 Network Ports and Expandability: The product features a compact 1U chassis design with six network ports. It can be expanded to support two or four 10 Gigabit Ethernet ports or four additional 1 Gigabit optical ports. This enhances networking capabilities and facilitates high-speed data transfer.

Share to:

Overview



The Partaker S11 firewall is a powerful network security device with multiple CPU options (i3 2350M, i5 3320M, i7 3520M, i7 3610M) and onboard Intel i225-B3 6 Ethernet ports. It offers expandability for 2-4 additional 10GbE or Gigabit SFP ports. With robust firewall capabilities, traffic monitoring, intrusion detection, and VPN features, it provides reliable network protection for businesses of all sizes.



Mechanical

Material Iron, Aluminum panel
Colour Gray
Size 440 x257 x 45(mm)(without mounting ear)
Weight 7.5Kgs
Insallation Method Rack Mounting/Wall Mounting/Desktop Mounting



Motherboard

CPU Intel Core I3-3110M, dual-core dual-thread, main frequency: 2.4GHz

(Optional 1005M/I3-2350M/I5-2520M/3320M/I7-3520M/3610M/3630QM)

Network Card Intel I225 2.5G adaptive network card interface, (optional I226 network card) can be expanded to 2/4 10 Gigabit or 4 Gigabit optical ports
Graphic Depend on CPUs
Memory 1 x DDR3L 1600MHz SODIMM memory slot, maximum support 8GB
Storage 1 mSATA SSD, 1 sata3.0
Display 1 x VGA, 1 x HDMI (Optional)
Expand Support 2 Mini-PCIE channels (can be WIFI/Bluetooth/4G) Support 1 PCIX8 channel expansion card slot
Others Support Power-on boot, scheduled boot, wake-up on LAN, PXE boot, watchdog



I/O Interfaces

Front Panel 1 x VGA
2 x Cooling fan
1 x Switch
1 x AC socket
Rear Panel 1 x Console
2 x 3.0
2 x optical ports (expandable to 4/2 Gigabit or 10 Gigabit optical ports)
6 x LAN



Software Support

System Support Windows,10,Server2012/EXSI/Ikuai/Mikrotik/Openwrt/Ubuntu/Centos/Pfsense/Linux
BIOS AMI EFI BIOS



General

Cooling Mode With Fan
Power Supply Industrial grade power supply Taiwan Mean Well LRS-50-12 Input: 100-240V~1.0A Output: 12V4.2A
Packing List S11 firewall, power cord, warranty card



Environment

Operating temperature -0~+50°C (commercial HDD), -20°C~+50°C (industrial SSD), surface air flow
ambient temperature 5~90°C relative humidity, non-condensing
Certification CE, FCC, CCC, ROHS
Model Processor Graphics Frequency Display Memory Storage LAN USB SFP Power
S11 I3 2350M Intel® HD Graphics 3000 2.30GHz 1 x VGA 1 x SO-DIMM DDR3L, Max 8GB 1 x mSATA/1 x 2.5 Inch SATA 6 2 2/4 12V4.2A
S11 I5 2520M Intel® HD Graphics 3000 2.5~3.20GHz 1 x VGA 1 x SO-DIMM DDR3L, Max 8GB 1 x mSATA/1 x 2.5 Inch SATA 6 2 2/4 12V4.2A
S11 I3 3110M Intel® HD Graphics 4000 2.400GHz 1 x VGA 1 x SO-DIMM DDR3L, Max 8GB 1 x mSATA/1 x 2.5 Inch SATA 6 2 2/4 12V4.2A
S11 I5 3320M Intel® HD Graphics 4000 2.6~3.30GHz 1 x VGA 1 x SO-DIMM DDR3L, Max 8GB 1 x mSATA/1 x 2.5 Inch SATA 6 2 2/4 12V4.2A
S11 I7 3520M Intel® HD Graphics 4000 2.9~3.60GHz 1 x VGA 1 x SO-DIMM DDR3L, Max 8GB 1 x mSATA/1 x 2.5 Inch SATA 6 2 2/4 12V4.2A
