Rack Mount Firewall N100
Model: Partaker R8
- Rack-Mount Firewall with metal build.
- Supports Intel Alder Lake-N CPUs.
- Up to 32GB DDR5 Memory.
- NVME & SATA Storage Options.
- 4x 2.5G + 4x 10G Networking Ports.
- VGA & HDMI Outputs.
- Effective Fan Cooling.
- Rack Ears Included.
- For Network Security.
- Power Adapter & Box Included.
Share to:
Overview
This rack-mount firewall features a robust sheet metal structure and an efficient fan design, supporting the Intel Alder Lake-N series processors including the N100, N150, and N305 quad-core options. It boasts a single 262-pin DDR5 SO-DIMM memory slot capable of accommodating up to 32GB of RAM, alongside one NVME slot and an additional SATA slot for versatile storage options, accommodating both M.2 SSDs and 2.5-inch HDD/SSDs. Networking capabilities are enhanced with four Intel i226 2.5G network cards and four X710 10G SFP+ modules for high-speed connectivity. For visual output, it includes one VGA port and one HDMI port. Powered by an included power adapter and plug, this device is ideal for network security, network management, and gateway applications. It comes complete with rack ears and a carton box for easy installation and transportation, making it a comprehensive solution tailored for rack-mounted firewall deployments.
| Model | Partaker R8 |
| Processor | Intel Alder Lake-N N100/N150/N305 |
| BIOS | AMI EFI BIOS (UEFI boot only) |
| Memory | 1*262 Pin DDR5 SO-DIMM Slot, up to 32GB |
| Storage | 1*M2_SSD(NVME/NGFF); 1*SATA (Support 2.5 inch HDD/SSD) |
| NIC Model | 4*Intel i226 2.5GbE (Backward compatible with 10/100/1000Mbps) |
| SFP Model | 4*X710 10G SFP+ |
| Video output | 1*VGA port; 1*HD MI port |
| Power supply | Jack DC 5.5/2.5mm 12V 6A |
| Expansion | 1*PCIe (USB protocol for LTE modules) |
| Other functions | Start auto after power restored; Wake-up on LAN; PXE; Watchdog |
| Applicable scene | Network Security, Network Management, Gateway, Edge computing, Industrial automation, Networking, Embedded systems, and home media servers. |
| Included accessories | 1*Power plug; 1*Power adapter; 1*Set rack ears 1* Carton box |
| Model | Processor | Cache | Memory | Storage | Display | Network Card | SFP | USB |
| R8 | N100 | 6M Cache, up to 3.40 GHz | 1*262 Pin DDR5 SO-DIMM Slot, up to 32GB | 1*M2_SSD(NVME/NGFF); 1*SATA (Support 2.5 inch HDD/SSD) | 1*VGA port; 1*HDMI port | 4*intel i226 2.5G network card | INTEL82599*2 X710*4 INTELI350*4 I350*4 | 4 |
