Mini PC 10th Gen Intel I5 1035G1/I7 1065G7

Mini PC 10th Gen Intel I5 1035G1/I7 1065G7

Model: Partaker B20

  • Intel® 10th Gen Intel® Core™ i5/i7 Processor
  • Dual SODIMM for up to 64GB DDR4 Memory
  • Support mSATA SSD, M.2 2280 SATA/NVME, 2.5 Inch SSD/HDD
  • Support Restore AC Power Loss
  • Rugged aluminum alloy case and silent fan dual cooling
  • Support 2 x HDMI display, HDMI 2.0 4K 4096 x 2304@60Hz

Share to:

Overview



Partaker B20 is a low-power, high-performance mini computer that can be equipped with a 10th generation Intel Core I7-1065G7 processor, ten nanometers, a new architecture, higher performance, better compatibility, and lower energy consumption. 8-layer immersion gold process bottom plate, highly integrated solid-state design, closed inductor, digital power IC, regardless of the cost of materials, to ensure stability, reliability, and life design for more than 10 years. Convenient and practical, it can meet various application requirements, such as image processing, video editing, programming learning, content browsing, and playing 3D games. Dual HDMI ports, supporting 4K@60Hz for the first time.


Mechanical

Material Aluminum alloy
Colour Silver & Black
Size 210 x 170 x 45mm
Weight 3Kgs
Insallation Method Desktop type/vesa mounting
With holding vertical stand, vesa mount as the optional



Motherboard

CPU Intel® Core™ i5-1035G1/1035G4 Processor (6M Cache, up to 3.60 GHz)
Intel® Core™ i7-1065G7 Processor (8M Cache, up to 3.90 GHz)
Chipset SOC
Network Card 2 x Intel RTL 8168/8111/8112 gigabit lan
WiFi and Bluetooth With dual antennas, 802.11ac 2.4+5Ghz, bt 4.0/4.2
Memory 2 x SODIMM DDR4, up to 64GB RAM
Storage 1 x 2.5 inch hard disk bay/1 x mSATA/1 x M.2 2280 (SATA/NVME)
Expand 2 x PCIE slot (half size and full size), with SIM slot



I/O Interfaces

Front Panel 1 x Power button
1 x Optical
2 x USB3.0
2 x USB2.0
1 x Audio
Rear Panel 1 x DC_in
2 x HDMI
2 x Lan
2 x USB3.0
2 x USB2.0
Side Panel 2 x WiFi antennas



Software Support

Bios AMI bios
System Support Windows 10, linux ubuntu etc



General

Cooling Mode Smart silent fan (place it vertically to reduce the fan speed & sound effectively)
Power Supply DC100-240V AC/50-60Hz, DC 12V/3A
Packing List B20 mini pc, power supply, power cord, vertical stand, wifi antennas, warranty card



Environment

Operating Temperature 0°C~70°C Centigrade (32°F~140°F)
Storage Temperature -20°C~80°C Centigrade (-68°F~176°F)
Relative Humidity 10%~90% (non-condensing)
Certification CE FCC ROHS



Model Processor Graphics Frequency Display Memory Storage LAN USB Power
B20 I5 1035G1 Intel® UHD Graphics 1.0~3.6 GHz 2 x HDMI 2 x SO-DIMM DDR4 1 x 2.5 inch/1 x M-SATA/1 x M.2 2280 (SATA/NVME) 2 8 12V/5A
B20 I7 1065G7 Intel® Iris® Plus Graphics 1.3~3.9 GHz 2 x HDMI 2 x SO-DIMM DDR4 1 x 2.5 inch/1 x M-SATA/1 x M.2 2280 (SATA/NVME) 2 8 12V/5A
