12th Gen Firewall Appliance 2*10G SFP

Mode: Partaker US1

CPU Options: N100 or i3-N305/N200.
RAM Compatibility: DDR5 4800MHz (up to 5600MHz).
Storage: M.2 NVMe, SATA 3.0, TF slot.
Graphics: Intel UHD.
Display Ports: HDMI, DP, Type-C (4K@60Hz).
Network Cards: 4x 2.5G Intel i226-V.
USB Ports: 1x USB 3.0, 5x USB 2.0.
Cooling: Dual heat pipe.
BIOS: AMI EFI with advanced features.
Design: Aluminum alloy, compact, wall-mountable.

Share to:

Overview

The Partaker US1 Micro Firewall Appliance is a compact, versatile networking device featuring Intel N100/N200/I3 N305 processor, comprehensive connectivity options, and compatibility with multiple OSes including FreeBSD, Linux, and Windows. It boasts easy configuration, robust firewall protection with pfSense and OPNsense compatibility, and is built with high-quality components for reliable performance, all enclosed in a durable aluminum casing with a silent cooling fan for long-term, low-heat operation.

Mechanical

Model	Partaker US1 Firewall Appliance
Processor	Intel Processor N100 6M Cache, up to 3.40 GHz Intel Processor N200 6M Cache, up to 3.70 GHz Intel i3-N305 Processor 6M Cache, up to 3.80 GHz
Installation method	Desktop (can contact to purchase wall mounts)
Memory	1 x SODIMM Up to DDR5 4800 MT/s, max. 32GB RAM
Storage	1 x M.2 2280 PCIe3.0 x1 SSD, not support internal SATA SSD/HDD, support knock-out holes DIY for external 2.5 Inch or above SATA SSD/HDD
AES-NI Supported	Yes
Display port	1HDMI2.0 4096×2160@60Hz 1DP1.2 4096×2160@60Hz 1*Type-C 4096×2160@60Hz
I/O	Power ON/OFF, Audio, Type-C for data/display, SIM slot, TF for data storage/some of the system boot, DP1.2, HDMI2.0, 5 x USB2.0, RST, USB3.0, DC_IN, 4 x LAN, 2 x SFP+ Optical
Network Card	4 x Intel 2.5GbE I226-V, 2 x SFP+ Optical, the sfp model is 10Gbe 82599ES
Expansion Pin	1 x Mini PCIE slot for USB signal 4G module, 1 x TPM pin, 1 x FPANEL pin, 1 x GPIO pin, 1 x COM pin
Cooling System	Dual copper tube turbo fans for active cooling
Size	155 x 131.7 x 60mm
Power Supply	DC100-240V AC/50-60hz, DC 12V-19V wide voltage, 12V8A
Graphics card	Intel UHD Graphics
BIOS	AMI EFi BIOS supports automatic start-up, watchdog, GPIO, PXE
Expandable	PCI-E x8 socket (x4 signal) can be plugged into Intel 82599ES dual 10G optical port Intel i210/i211/i226-V four network ports \| 4 x1 signal M.2 adapter boards
Structure Parameter :
Color	Cool black, iron gray (no color is noted, random color is shipped)
Material	Aluminum alloy
Packing List	Firewall appliance, power supply, power cord, warranty card
Weight	1.3 kg
Environmental Parameters :
Work Temp	-0°C~+70°C
Relative humidity	5%-85%

Processors	Cores & Threads	Cache	Max Turbo Frequency	TDP	Graphics
Intel N100	4 cores, 4 threads	6M	3.40 GHz	6W	Intel UHD Graphics 750MHz 24EUS
Intel N200	4 cores, 4 threads	6M	3.70 GHz	6W	Intel UHD Graphics 750MHz 32EUS
Intel Core i3-N305	8 cores, 8 threads	6M	3.80 GHz	9-15W	Intel UHD Graphics 1250MHz 32EUS
