Firewall Mini PC 10Gbe SFP

Mode: Partaker US2

Dual 10G SFP+ & 2.5G LAN Ports.
Supports DDR5 Memory up to 4800MHz.
Triple Storage Options.
WiFi 6 & Bluetooth Ready.
TF Card Slot for Extra Storage.
Dual 4K Display Support.
Advanced Security & Management Features.
Flexible Cooling Options.
Efficient, Low TDP Design.
Robust Aluminum Case.

Share to:

Overview

The 12th Gen Firewall Mini PC is a compact yet powerful solution designed for high-performance networking and security applications. Featuring 2x10G SFP+ and 2×2.5G RJ45 LAN ports, it ensures ultra-fast data transfer and reliable connectivity. Powered by Intel i3 N305/N100 processors, it supports DDR5 RAM, dual M.2 NVMe SSDs, and SATA storage, offering exceptional flexibility for storage and system boot. With advanced features like AES-NI encryption, ESXI/PVE virtualization, and 4K dual display support, this mini PC is ideal for firewalls, soft routers, and network security deployments.

Mechanical

Category	Specification
Processor	Intel’s 12th Generation Low Power Platform
Network Ports	2x 10G optical ports (Intel 82599ES chip)
Network Ports	2x 2.5G network ports (Intel i226-V chip)
Storage	2x M.2 2280 NVMe (1 native, 1 converted from M.2 E key)
Storage	1x 2.5-inch SATA3.0 SSD/HDD (with 4-pin power supply socket)
Memory	1x SO-DIMM DDR5 laptop memory slot (max 32GB)
USB Ports	1x USB 3.2 Gen1, 4x USB 2.0, 1x Type-C USB 3.2 Gen1 (data only)
Display	2x HDMI 2.0 (supports 4K@60Hz synchronous/asynchronous display)
Expansion	M.2 E key 2230 socket (supports WiFi & Bluetooth module, convertible to M.2 2280 NVMe with adapter board)
Support OS	Preinstall windows 11 pro Compatiable with Pf-sense / OPNsense/ Ubuntu /Windows /VM OS(like ESXI/PROXMOX/Debian etc.(some OS Version not compatible with network card)
Additional Features	TF card socket (supports data storage and partial system boot)

Processors	Cores & Threads	Cache	Max Turbo Frequency	TDP	Graphics
Intel N100	4 cores, 4 threads	6M	3.40 GHz	6W	Intel UHD Graphics 24EUS
Intel Core i3-N305	8 cores, 8 threads	6M	3.80 GHz	15W	Intel UHD Graphics 32EUS
Intel N150	4 cores, 4 threads	6M	3.60 GHz	6W	Intel UHD Graphics 24EUS
Intel Core 3-N355	8 cores, 8 threads	6M	3.90 GHz	15W	Intel UHD Graphics 32EUS
