1U Firewall Server Hardware C3958 C3758 C3808

Model: Partaker R13

Robust performance with C3758/C3958/C3808 processors.\
Enhanced encryption for data protection.
Smooth multitasking with expandable memory.
M.2 NVMe & 2.5″ SATA options.
Multiple GbE & SFP+ ports.
Console, USB, LAN, optical, VGA ports.
Mini PCIe, M.2, PCIe x8 for upgrades.
1U rack-mountable chassis.
Ensures long-term stability.
FreeBSD, Linux, Windows compatible.

Share to:

Overview

Introducing our versatile 1U Firewall Server Hardware, powered by Intel Atom C3758/C3958/C3808 processors, compatible with FreeBSD, Linux, and Windows, featuring robust firewall support for pfSense, OPNsense, and other open-source solutions, with UEFI-only support, 10 LAN, 4 SFP+ optical ports, low power consumption, and a silent cooling fan, all packed in a compact 1U rackmount form factor ready for immediate deployment.

Model Number	Partaker R13
CPU	Intel Atom C3758/C3808/C3958 Processor
BIOS	AMI BIOS (Legacy or UEFI)
AES-NI Supported	Yes
Memory	2 x SODIMM DDR4 2400 MT/s, MAX.64GB RAM
Storage	1 x M.2 2280 NVME PCIE3.0 x2 SSD, 1 x 2.5 Inch SATA SSD/HDD
Network Card	2 x Intel I211 1GbE LAN, 4 x I350 1GbE LAN, 4 x I225-V 2.5GbE LAN, 4 x SFP+ Optical, the SFP+ model is X553
Display Port	1*VGA port (Aspeed BMC chip)
I/O	Console, USB2.0, USB3.0, 10 x LAN, 4 x SFP+ Optical, AST 2400 VGA, Power Switch, AC Socket
Expansion	1 x Mini PCIE slot for WiFi/4G, 1 x M.2 3052 USB3.0 x1 signal slot for WiFi/4G, with SIM slot, 1 x PCIe x8 slot
Chassis	1U 19 inch cabinet, rackable, with mounting bracket ears, wall hanging, foot pad
Power	100-240V1.0A, 12V6.25A
Cooling System	The processor uses the ball silent cooling fan to ensure the long time work and stable cooling
Size	484 x 252 x 48mm
Packing List	Firewall appliance, rackable ears, power cord, warranty card
Function	Supports hardware auto power on enabled default, Scheduled boot, Wake-up on LAN, PXE boot, Watchdog
System Compatibility	5.10.x and above core-based freebsd router systems, linux distros, or win.os supported
Compatibility	Firewalls for pfsense, opnsense and other popular open-source software solutions

Model	Processor	Cache	Memory	Storage	Display	Network Card	USB	Power
R13	C3758	16M Cache, up to 2.20 GHz	2 x SO-DIMM DDR4, Max 64GB	1 x M.2 2280 NVME PCIE3.0 x2 SSD, 1 x 2.5 Inch SATA SSD/HDD	1 x VGA	2 x Intel I211 1GbE LAN, 4 x I350 1GbE LAN, 4 x I225-V 2.5GbE LAN, 4 x SFP+ Optical, the SFP+ model is X553	2	100-240V1.0A, 12V6.25A
R13	C3808	12M Cache, up to 2.0 GHz	2 x SO-DIMM DDR4, Max 64GB	1 x M.2 2280 NVME PCIE3.0 x2 SSD, 1 x 2.5 Inch SATA SSD/HDD	1 x VGA	2 x Intel I211 1GbE LAN, 4 x I350 1GbE LAN, 4 x I225-V 2.5GbE LAN, 4 x SFP+ Optical, the SFP+ model is X553	2	100-240V1.0A, 12V6.25A
R13	C3958	16M Cache, up to 2.0 GHz	2 x SO-DIMM DDR4, Max 64GB	1 x M.2 2280 NVME PCIE3.0 x2 SSD, 1 x 2.5 Inch SATA SSD/HDD	1 x VGA	2 x Intel I211 1GbE LAN, 4 x I350 1GbE LAN, 4 x I225-V 2.5GbE LAN, 4 x SFP+ Optical, the SFP+ model is X553	2	100-240V1.0A, 12V6.25A
